18650 Battery Module DIY PCB Kit 10x
18650 Battery Module DIY PCB Kit 10x
18650 Battery Module DIY PCB Kit 10x
18650 Battery Module DIY PCB Kit 10x
18650 Battery Module DIY PCB Kit 10x

18650 Battery Module DIY PCB Kit 10x

Regular price $89.99

This is the basic kit it includes everything to make a 70 18650 cell battery pack 24v +- 700wh (7s10p). Requires Assembly and soldering.


PCB KIT (included)
Contents: Battery Module PCB DIY Kit

10x Printed Circuit Boards
10x 4cell 18650 holders
10x 3cell 18650 holders
10x 5A SMD fuses
10x IDC Socket connector
10x IDC Ribbon connector
1x Ribbon cable
1x XT60 connector
4x M4 Lug PCB Terminal
40x M4x 25mm standoffs
Download PCB v1.3 Gerber

PCB Board - Assembly Required

BMS KIT (optional)
Contents: Battery Management System DIY Kit

1x PCB
3x 20A BMS units
3x 3M Double sided Adhesive
2x 35A Fuses with Bases
4x M4 screw terminals
4x M4 Nuts
4x M4 screws
4x M4x25mm standoffs
1x 6" solid copper wire
1x XT90 Pigtail
1x 16pin IDC socket connector
1x 16pin IDC connector
 Download BMS Gerber


SOC KIT (optional)
Contents: 7s State of Charge Meter DIY Kit

42x Resistors (Various 1,2,3,4,5)
1x Dip Switch
1x PCB
7x LM3914n
7x 10segment LED
4x M4 Screws
4x M4 Nuts
4x M4x 25mm Standoffs
4x Nylon standoffs
7x 5A fuses
Download S7 SOC Gerber File
