16pcs LiFePO4 3.2v 20ah 200A High Discharge Current 20Ah Battery Cells

  • Sale
  • Regular price $284.05
Shipping calculated at checkout.


16pcs LiFePO4 3.2v 20ah 200A High Discharge Current 20Ah Battery Cells


SPECS

Item

Specification

Remark

Rated capacity

20Ah

0.2C rate discharge capacity

Minimum capacity

20Ah

Internal impedance

       0.8±0.1mΩ



Nominal voltage

3.2V



Dimensions

    148*27*98mm



Cell weight      0.65±0.03 kg





Standard discharge

conditions

Recommend Constant Current

10A(0.5C)



End-of-Discharge Voltage

2.5V



Standard Charge

Method

Recommend  Constant Current

10A(0.5C)



 Charge Voltage

3.65V



Fast Charge Method

Constant Current

20A(1C)



Charge Voltage

3.65V



Max Continuous Discharge Current

200A(10C)



Cycle life

3000 cycles

80% DOD

Operating temperature

Charging ambient          temperature

0~45°C



Discharging     ambient

temperature

-25~65°C



Storage temperature

0~45°C



Appearance

Without break,

distortion, contamination,

leakage.
